| Model name | SCS2365 |
| Description | 23.6” TFT LCD,1000nits,1920x1920 Circle SDM Solutions |
| Size | 23.6” |
| Display Area (mm) | 596.16(H) x 596.16(V) |
| Brightness | 1000 cd/m² |
| Resolution | 1920x1920 |
| Aspect Ratio | 1:1 |
| Contrast Ratio | 600:1 |
| Pixel Pitch (mm) | 0.3105(H) x 0.3105(V) |
| Pixel Pre Inch (PPI) | 82 |
| Viewing Angle | 178°(H),178°(V) |
| Color Saturation (NTSC) | 77% |
| Display Colors | 16.7M |
| Response Time (Typical) | 8ms |
| Video interface | SDM-S/SDM-L interface |
| SDM Slot | SDM-S/SDM-L |
| Input Power | AC100~240V |
| Power Consumption | 60W (Panel Model Only) |
| Dimensions (mm) | 890 x 890 x 77.2 |
| Weight (Net) | 24kg |
| Mounting | VESA 400x200, 400x400 |
| OSD key | 5 Keys (Power Switch, Menu, +, Exit -) |
| OSD control | Brightness, Color, Contrast, Auto Turing, H/V Position…etc |
| Operating Temperature | 0 ˚C ~ 50 ˚C |
| Storage Temperature | -20 ˚C ~ 60 ˚C |
