| Model Name | SCD2364-C | ||
| Description | 23.6” TFT LCD, 1000nits LED Backlight, 848 x 848, Double Side Circle Display | ||
| size | 23.6” | ||
| Display area (mm) | 600.384(H) x 600.384(V) | ||
| Brightness | 700 cd/m² | ||
| Resolution | 848 x 848 | ||
| Aspect ratio | 1:1 | ||
| Contrast ratio | 6200:1 | ||
| Pixel pitch (mm) | 0.708(H) x 0.708(V) | ||
| Pixel per inch (PPI) | 51 | ||
| Viewing angle | 178°(H),178°(V) | ||
| Color saturation (NTSC) | 83% | ||
| Display colors | 16.7M | ||
| Response time (Typical) | 8ms | ||
| Video interface | HDMI x 2, DP x 2 | ||
| Input power | AC100~240V | ||
| Power consumption | 129 W | ||
| Dimensions (mm) | HDMI x 2, DP x 2 | ||
| Weight (Net) | 22.5 kg | ||
| Mounting | VESA 280x120, 140x120 | ||
| Operating temperature | 0 ˚C ~ 50 ˚C | ||
| Storage temperature | -20°C ~ +60°C | ||
