Modular Panel PCs & Monitors
IPPC-5500-AML0-WG00-1001
55” TFT LCD, LED Backlight 2500 nits, FHD (1920x1080)
▪ High Brightness: 2500nits (min)
▪ Sunlight Readable
▪ Low Power Consumption
▪ 5mm AG UV/IR Tampered Glass
▪ Full IP56 / IK10
▪ Auto Dimming / IR-Remote
▪ LCD Blacking Defect Free (H-Tni 110℃)
▪ Slim Bezel ▪ BL MTBF: 100,000 hours
▪ Sunlight Readable
▪ Low Power Consumption
▪ 5mm AG UV/IR Tampered Glass
▪ Full IP56 / IK10
▪ Auto Dimming / IR-Remote
▪ LCD Blacking Defect Free (H-Tni 110℃)
▪ Slim Bezel ▪ BL MTBF: 100,000 hours
Main Features
-
Wide Viewing Angle
-
Transportation
-
Traffice Recognition
-
Touch Screen
-
Sunlight Readable
The IPPC-5500-AML0-WG00-1001 is 2500nits high-brightness display ensures clear visibility in direct sunlight, making it ideal for outdoor and industrial applications. Featuring 5mm AG UV/IR tempered glass, IP56/IK10 durability, and low power consumption, it offers reliability in harsh environments. Auto-dimming, IR remote control, and LCD Blacking Defect Free (H-Tni 110°C) technology enhance performance, while the 100,000-hour backlight MTBF ensures longevity. With a slim bezel design, it delivers both durability and a sleek, modern look.
| Model Name | IPPC-5500-AML0-WG00-1001 | ||
| Description | 55” TFT LCD, LED Backlight 2500 nits, FHD (1920x1080) | ||
| size | 55" | ||
| Display area (mm) | 1209.6(H) x 680.4(V) | ||
| Brightness | 2500 cd/m2 | ||
| Resolution | 1920 x 1080 | ||
| Aspect ratio | 16 : 9 | ||
| Contrast ratio | 1500 : 1 | ||
| Pixel pitch (mm) | 0.63(H) x 0.63(V) | ||
| Viewing angle | 178° (H), 178° (V) | ||
| Color saturation (NTSC) | 80% | ||
| Display colors | 16.7M | ||
| Response Time (Typical) | 9ms | ||
| Glass | 5mm AG UV/IR Tampered Glass | ||
| IK Level | IK10 | ||
| IP Level | IP56 | ||
| CPU | AML T982，Quad-Core ARM Cortex-A55 | ||
| RAM | DDR4 4GB | ||
| Storage | eMMC 32GB | ||
| Interface | RJ45x1、HDMI in x 2 、USB3.0x1、USB2.0x1 | ||
| OS | Android 14.0 ( Android Open Source Project) | ||
| Power input | AC 100~240V | ||
| Power Consumption | 300W (typ.) | ||
| Dimensions (mm) | 1260.6 x 731.4 x 108 | ||
| Weight (Net) | 58 kg (est.) | ||
| Operating Temperature | -30 ˚C ~ 50 ˚C | ||
| Storage Temperature | -40 ˚C ~ 70 ˚C | ||
