Home / Product / Industrial Computing / Embedded Box PCs / Entry BOX PC / IBOX-APL7-C-TYPE

Entry BOX PC

IBOX-APL7-C-TYPE

Fanless Embedded System with Intel® ATOM™/Pentium®/ Celeron® processor, DP, 3 USB and GbE LAN
  • Intel®  ATOM™/Pentium®/ Celeron® processor
  • 1 x 204-pin DDR3L 1866MHz SDRAM; max. up to 8GB
  • 1 DP, 2 USB 3.0, 1 USB2.0, 3 COM, 1 LAN
  • 1 full-size mPCIe and 1 x M.2 B+M-key 3042 for expasion
  • 12 to 36VDC wide range DC input
PRINT
INQUIRY COMPARE

Main Features

  • Fanless

SPECIFICATION DOWNLOAD
Model name IBOX-APL7 C TYPE
System
CPU Intel® AtomTM x7 E3950 1.6GHz (12W)
Intel® AtomTM x5 E3940 1.6GHz (9.5W)
Intel® AtomTM x5 E3930 1.3GHz (6.5W)
Intel® Pentium® N4200 QC 1.1GHz (6W)
Intel® Celeron® N3350 DC 1.1GHz (6W)
Chipset Intel® Apollo Lake-I SoC intrgrated
BIOS AMI UEFI Flash ROM
System memory 1 x 204-pin DDR3L 1866MHz SDRAM; max. up to 8GB
Graphic Intel® HD Gen. 9-LP graphics
Watchdog timer Yes
I/O
USB 2 x USB 3.0, 1 x USB 2.0
COM 3 x COM (1 x RS232/422/485, 2 x RS232)
LAN 1
Display 1 x DP
Audio N/A
PS/2 N/A
Others 2 x SMA hole
Storage Support
HDD 1 x 2.5" HDD
M.2 1 x M.2 M-key 2242
mSATA N/A
Expansion
Mini-PCIe 1 x Full-size
M.2 1 x M.2 B+M-key 3042 (WWAN w/uSIM)
Power
Power supply Wide range DC 12V or 19 ~ 24V input (by jumper selection), Phoenix connector
Environmental
Operating Temperature 0°C ~ 60°C (Optional -20°C, -40°C)
Storage Temperature -20°C ~ 80°C
Relative Humidity 0% ~ 90% (non-condensing)
Mechanical
Construction Aluminum extrusion and heavy-duty steel
Standard color Silver
Mounting Wall / VESA 100 / DIN(Optional)
Weight 1 kg
Dimensions (W)x(D)x(H)mm 178 mm(W) x 123.2 mm(D) x 49.8mm(H)
