Home / Product / Industrial Display / ECOgreenpixel / EPD2539-EGP

ePaper Display

EPD2539-EGP

25.3” ECO green reflective full color display
  • Reflective ePaper display
  • Full color 30K
  • Ultra low power consumption
  • High Resolution 1800 x 3200
  • Sunlight readable
  • Build in powerful processor
  • Protection cover glass
PRINT
INQUIRY COMPARE

Main Features

  • Sunlight Readable

  • Low Power Consumption

SPECIFICATION DOWNLOAD
Model Name EPD2539-EGP-A11
Description 25.3” ECO green reflective full color display
size 25.3"
Display Area (mm) 313 (H) x 558 (V)
Resolution 1800 x 3200
Aspect Ratio 9 : 16
Color 30K
Reflectance 25%
Contrast Ratio 15
Image Update Time 30 sec
Main Board Processor Arm A35 1.3GHz quad core
Flash Memory 2GB DDR3
Storage Memory 16GB EMMC
I/O Interface USB x2, RJ45 (LAN)
Operation System Android 11
Wireless WiFi 2.4G/5G
Front Light Optional
Cover Glass Optional
Power Input DC 20V
Max. Power Consumption 8W (During Update Image)
Study by Power Consumption 0.1W
Dimensions (mm) 343.6 x 588.6 x 34.1
Weight (Net) 2.9kg
Mounting 100 x 200, 130 x 480
Operating Temperature 15 ˚C ~ 35 ˚C
Storage Temperature -25 ˚C ~ 50 ˚C
