Model Name | EPD1332-EGP-A11 | |||
Description | 13.3” ECO green reflective monochrome display | |||
size | 13.3” | |||
Display area (mm) | 202.8 (H) × 270.4 (V) | |||
Resolution | 1200 x 1400 | |||
Aspect ratio | 3 : 4 | |||
Color | Monochrome 16 gray | |||
Reflectance | 40% | |||
Contrast ratio | 12 | |||
Image Update Time | 0.5 sec | |||
Main Board Processor | Arm A35 quad core process | |||
Flash Memory | 2GB DDR4 | |||
Storage Memory | 32GB EMMC | |||
I/O Interface | SIM card, Type-C | |||
Operation System | Android 8.1 | |||
Wireless | WiFi 2.4G (Optional) | |||
Front Light | Optional | |||
Cover Glass | Optional | |||
Power Input | TBD | |||
Dimensions (mm) | 255 x 320 x 40 | |||
Weight (Net) | TBD | |||
Operating temperature | -10 ˚C ~ 55 ˚C | |||
Storage temperature | -20 ˚C ~ 55 ˚C |
Download
-
Title
DS/ELD1332-EGP
TypeDatasheet
Publish Date2024/Sep/20
