Home / Product / Accessories / AD Board / AD68862HP

Display Control Board,FHD

AD68862HP

Display Control Board, FHD(1920x1 080)
  • Max Resolution Up To QHD (1920x1080)
  • Support eDP & LVDS panel
  • HDMI 1. 4 Input (1920x1080@60Hz)
  • e-DP interface (2 Lanes)
  • Dual/Single LVDS in terface
  • EN and PWM or DC dimming for backlight
  • Support Panel DC 3.3V/5V/12V Output
  • OSD Control
  • External RS232 control (Optional)
  • Input Power 12V DC or 24V DC (Optional)
  • External Digital Light Sensor Brightness Control (Optional)
  • External Light Sensor Brightness Control or VR (Optional)
  • Support Output Voltage 12V(1A) or 5V(1A)
PRINT
INQUIRY COMPARE
SPECIFICATION DOWNLOAD
Model name AD68862HP
Chipset NT68862UFG/C
Max. Resolution FHD (1920x1080)
Interface eDP 2 Lanes, Dual/Single LVDS
Input Power DC 12V or 24V
Panel Power Selection 3.3V, 5V, 12V
Video Input (Standard) HDMI, DP
RS232 Control Port Yes (Optional)
Light Sensor Yes (Optional)
External VR Control Yes (Optional)
Dimension 100 x 72 mm
F / R Control Button 4 Key
4 key Power Switch, Menu, Select (+,-)
OSD Menu Brightness, Color, Contrast, Auto Turing, H/V Position…etc
Inputs HDMI, DP
Resolution 1920x1080
