3.5" Single Board Computers
AECX-EHL0
Intel® Atom®/ Pentium®/ Celeron® Series SoC based 3.5" Embedded Board with DP (HDMI)/2 LVDS, SATA III, 2 COM, 6 USB, Intel® GbE LAN.
- Intel® Elkhart Lake Atom®/ Pentium®/ Celeron® series SoC onboard
- One 204-pin SO-DIMM up to 32GB DDR4 3200MT/s SDRAM
- Multi-Display : HDMI (DP) / 2 LVDS
- Two Intel® Gigabit Ethernet port
- 1 Mini PCIe (full-size), 1 M.2 B+M-key 3042
- 1 SATA III, 3 USB 3.1, and 3 USB 2.0 ports
- Supports 4K/2K Resolution Display
- DC-IN 12V or 19V ~ 24V, EuP/ErP 2013 ReadyEuP/ErP 2013 Ready
Main Features
-
Quad Display
-
Multi Tasking
-
M.2
AECX-EHL0, the new embedded single board powered by the Intel® 11th Generation Core™ Processors. The new generation solutions provide greater performance. Optimized for IOT solutions including Industrial, Energy, Visual and Transaction Retail, Office Automation, Gaming, Health Care, Public Sector, featuring the Intel® Iris Xe Graphics, 4K at 60Hz, 12 lan HSIO, DDR4 3200 memory, and Intel® GP low power compute, OOB manageability.
Integrated with 10nm microarchitecture 11th Gen. Intel® Core™ processors that presents excellent computing performance that up to 40% faster than the previous ATOM models, 2X graphics performance upgrade and responsiveness with 4.5-12W low power consumption. Adopting up to 32 GPUs and dual video decoder boxes with Intel Iris® Xe graphics, AECX-EHL0 supports up to dual ports independent 4K displays. Meanwhile, this platform is known for Industrial applications span applications driving intelligence at the edge in conjunction with low power consumption. In response to this, Intel is offering manufacturers Elkhart Lake with lower power and higher performance.
AECX-EHL0 facilitates M.2 and mPCIe expansions: One B+M-Key for 5G/LTE modules/SATA SSD, and M-key for NVMe/PCIe SSD; One mPCIe for Wifi/BT/GPS module. On top of these rich features, it also comes with dual Intel® LAN ports and feature-rich IOs and expansion slots, such as three USB 3.1, three USB 2.0, two COM and with 12V or 19~24V DC-in / ATX power input for versatile and wide-voltage industrial applications.
Integrated with 10nm microarchitecture 11th Gen. Intel® Core™ processors that presents excellent computing performance that up to 40% faster than the previous ATOM models, 2X graphics performance upgrade and responsiveness with 4.5-12W low power consumption. Adopting up to 32 GPUs and dual video decoder boxes with Intel Iris® Xe graphics, AECX-EHL0 supports up to dual ports independent 4K displays. Meanwhile, this platform is known for Industrial applications span applications driving intelligence at the edge in conjunction with low power consumption. In response to this, Intel is offering manufacturers Elkhart Lake with lower power and higher performance.
AECX-EHL0 facilitates M.2 and mPCIe expansions: One B+M-Key for 5G/LTE modules/SATA SSD, and M-key for NVMe/PCIe SSD; One mPCIe for Wifi/BT/GPS module. On top of these rich features, it also comes with dual Intel® LAN ports and feature-rich IOs and expansion slots, such as three USB 3.1, three USB 2.0, two COM and with 12V or 19~24V DC-in / ATX power input for versatile and wide-voltage industrial applications.
| Model name | AECX-EHL0 |
| Form Factor | 3.5" Embedded |
| Dimensions (L)x(W)mm | 146mm x 102mm (5.75” x 4.01”) X 17.3mm |
| Processor |
Atom® x6425E (2.0GHz/3.0GHz) Atom® x6413E (1.5GHz/3.0GHz) Pentium® J6426 (2.0GHz/3.0GHz) Pentium® N6415 (1.2GHz/3.0GHz,16EU, 6.5W) Celeron® J6412 (2.0GHz/2.6GHz,QC,16EU, 10W) Celeron® N6211 (1.2GHz/3.0GHz,DC,16EU, 6.5W) |
| Chipset | Intel® Elkhart Lake SoC integrated |
| BIOS | AMI® UEFI Flash ROM |
| LAN Controller | Intel® I211 GbE / Intel® I210 GbE |
| Audio Codec | Realtek® ALC888S HD Audio Codec |
| Watchdog Timer | Yes |
| Memory | |
| Technology | DDR4 SDRAM up to 3200 MT/s |
| Max. Capacity | Up to 32GB |
| Socket | 1 x 204-pin SO-DIMM |
| Display | |
| Graphic | Intel UHD Graphics 10th Gen Graphics |
| Display Interface |
2 x HDMI v2.0b or DP v1.4a (BOM Change) 2 x LVDS 2-channel 18/24-bit 1 x eDP v1.3 (optional) |
| I/O | |
| Expansion Slot | 1 x M.2 B+M-Key 3042 (WWAN, w/ μSIM) / 2242 (SSD) |
| LAN | 2 x 10/100/1000 Mbps |
| Serial ATA | 1 x SATAIII |
| Audio | Line-in, Line-out, Mic-in (Box Header) |
| USB | 3 x USB 3.1 (rear I/O), 3 x USB 2.0 (2 box-header) |
| COM |
1 x RS-232/422/485 (box-header) 1 x RS-232 (box-header) |
| Display | 2 x HDMI or DP, 2 x LVDS |
| Digital I/O | 1 x I2C (box-header) |
| SMB | 1 x SMBus |
| PS/2 | N/A |
| Power Requirement | |
| Power connector | ATX 4P or DC-Jack |
| Power Type | DC-IN 12V or DC-IN 19V~24V |
| Power Mode | AT/ATX (by jumper selection) |
| Environment | |
| Storage Temperature | -40°C ~ 80°C (-40°F ~ 176°F) |
| Relative Humidity | 0% ~ 95% (non-condensing) |
| Operating Temperature | 0°C ~ 60°C (32°F ~ 140°F) |
