Module d’affichage intelligent Intel®

ASDM-APL5

Intel® Smart Display Module(Intel® SDM) with Intel® Atom® E3900 processor, COM, 2 USB, One GbE LAN.
  • Intel® Apollo Lake SoC on board
  • One 204-pin SO-DIMM DDR3L up to 1866MT/s 8GB SDRAM
  • One Intel® Gigabit Ethernet ports
  • M.2 (M-Key 2242), M.2 (E-Key 2230)  expansion slots
  • COM, 2 USB 3.0
  • EuP/ErP 2013 Ready
IMPRIMER
DEMANDE COMPARER
INTRODUCTION Spécifications
L’ASDM-APL5/APL6 est conforme au module Intel® Smart Display. Il est alimenté par un processeur embarqué Intel® ATOM®/Pentium®/Celeron® (nom de code : Apollo Lake) et constitue un module tout-en-un ultra-fin, permettant un écran plus mince.
L’ASDM-APL5/APL6 peut être facilement connecté à un écran compatible SDM via un connecteur PCIe edge haute vitesse, supportant les affichages 4K et la capture vidéo, avec des interfaces intégrées telles que USB 3.0, HDMI 1.4, DisplayPort 1.2, ainsi que les signaux Serial TX/RX et I2C.

Le module Intel® Smart Display (Intel® SDM) est une solution évolutive, pérenne et plug-and-play pour la signalisation numérique. Sa conception sans boîtier permet une intégration complète dans des applications visuelles IoT nécessitant un espace minimal tout en offrant des performances maximales.
L’intégration des écrans et des capacités informatiques modulaires offre des fonctionnalités riches tout en facilitant la réparation et la mise à niveau.
Model name ASDM-APL5
Form Factor Smart Display Module
Dimensions (L)x(W)mm 175 mm x 100 mm
Processor Intel® Atom™ x5-E3940 1.60GHz / 1.80GHz (Base/Burst) Quad-Core SoC (9.5W)
Intel® Pentium® x7 E3950 1.60GHz / 2.00GHz (Base/Burst) Quad-Core SoC (12W)
Intel® Celeron® x5 E3930 1.30GHz / 1.80GHz (Base/Burst) Dual-Core SoC (6.5W)
Intel® Ato
Chipset Intel® Apollo Lake SoC integrated
BIOS AMI UEFI Flash ROM
LAN Controller Intel® I211 GbE
Audio Codec Realtek ALC662 HD
Memory
Technology DDR3L up to 1866MHz SDRAM
Max. Capacity Up to 8GB
Socket 1 x 204-pin SO-DIMM
Display
Graphic Intel® HD Gen. 9-LP Graphics
Display Interface DP / HDMI (Golden Finger)
I/O
Expansion Slot 1 x M.2 E-key 2230 (WiFi/BT), 1 x M.2 M-key 2242 (SSD)
LAN 1 x 10/100/1000 Mbps
Audio MIC-in, Line-out,
USB 2 x USB 3.0 (Rear I/O)
COM 1 x RS-232/422/485 (Rear I/O)
Display HDMI , DP (Golden Finger)
Environment
Operating Temperature 0°C ~ 60°C (32°F ~ 140°F) standard
-20°C ~ 70°C (-4°F ~ 158°F) optional
-40°C ~ 70°C (-40°F ~ 158°F) optional
-40°C ~ 80°C (-4°F ~ 176°F)
Relative Humidity 0% ~ 95% (non-condensing)
