Heim / Produkte / Industrial Display / Custom LCD Displays / SCD2364-C

Round Display-Double Side

SCD2364-C

23.6” TFT LCD, 700nits LED Backlight, 848 x 848, Double Side Circle Display
  • 23.6" Double Side Circle Display
  • Brightness 700nits
  • Double Side RGB Circle Lighting
  • Aspect Ratio 1:1
  • LED Backlight
  • Low Power Consumption
  • BL MTBF: 50,000 hours
Drucken
Anfrage Vergleich
Spezifikationen DOWNLOAD
Model Name SCD2364-C
Description 23.6” TFT LCD, 1000nits LED Backlight, 848 x 848, Double Side Circle Display
size 23.6”
Display area (mm) 600.384(H) x 600.384(V)
Brightness 700 cd/m²
Resolution 848 x 848
Aspect ratio 1:1
Contrast ratio 6200:1
Pixel pitch (mm) 0.708(H) x 0.708(V)
Pixel per inch (PPI) 51
Viewing angle 178°(H),178°(V)
Color saturation (NTSC) 83%
Display colors 16.7M
Response time (Typical) 8ms
Video interface HDMI x 2, DP x 2
Input power AC100~240V
Power consumption 129 W
Dimensions (mm) HDMI x 2, DP x 2
Weight (Net) 22.5 kg
Mounting VESA 280x120, 140x120
Operating temperature 0 ˚C ~ 50 ˚C
Storage temperature -20°C ~ +60°C
