2.5" Pico-ITX Boards
APIX-KBL7
Pico-ITX Embedded Board with Intel® 7th Gen Core™ i7/i5/i3 / Celeron® processors, HDMI(DP)/LVDS, SATA III, 2 COM, 5 USB, AMIO, Intel® GbE LAN.
- Intel® 7th Gen Core™ i7/i5/i3 and Celeron® Processors on board
- One260-pin SO-DIMM DDR3L up to DDR4 SDRAM up to 2133 MHz
- Multi-Display: HDMI(DP)/LVDS/AMIO (DP v1.2 interface, optional)
- 1 M.2 E-Key 2230 (WiFi/BT), 1 M.2 M-Key 2242 (MVMe), 1 AMIO expansion slots
- 1 SATA III, 2 COM (1 w/ either COM or DIO), 2 USB 3.0 and 3 USB 2.0
- Supports 4K/2K Resolution Display
- DC-in 12V, EuP/ErP 2013 Ready
Main Features
-
Multi Display
-
Fanless
APIX-KBL7, the latest addition to its family of PICO-ITX form factor is the compact Embedded Boards in the size of 100x72mm, it creates and fulfills various space-constrained applications. And small footprint doesn’t necessarily sacrifice expandability, the 2.5" PICO-ITX boards have low power consumption, support multiple I/O and an extended temperature depending on the equipment variant.
Industry 4.0 is rapidly transforming infrastructure requirements. As a consequence, there is an increasing demand for space-constraint applications, such as those based on a Pico-ITX form factor. The compact design, plus the basic embedded feature set, makes our Pico-ITX highly versatile. Thanks to their low power consumption with a TDP of between 6 and 12 Watt, our single-chip Pico-ITX solutions are particularly well suited for passively cooled and enclosed systems that can be used without any concerns in harsh environments. Typical applications include control of large machines with decentralized, distributed intelligence, robotics, all types of intelligent measurement and analysis devices, and high-performance IoT computers with low power consumption.
APIX-KBL7, PICO-ITX board is capable of powering a range of Intel® MovidiusTM VPU to bring the AI and Edge Computing for industrial and embedded application such as smart factory, smart retail, and smart city.
Industry 4.0 is rapidly transforming infrastructure requirements. As a consequence, there is an increasing demand for space-constraint applications, such as those based on a Pico-ITX form factor. The compact design, plus the basic embedded feature set, makes our Pico-ITX highly versatile. Thanks to their low power consumption with a TDP of between 6 and 12 Watt, our single-chip Pico-ITX solutions are particularly well suited for passively cooled and enclosed systems that can be used without any concerns in harsh environments. Typical applications include control of large machines with decentralized, distributed intelligence, robotics, all types of intelligent measurement and analysis devices, and high-performance IoT computers with low power consumption.
APIX-KBL7, PICO-ITX board is capable of powering a range of Intel® MovidiusTM VPU to bring the AI and Edge Computing for industrial and embedded application such as smart factory, smart retail, and smart city.
| Model name | APIX-KBL7 |
| Form Factor | 2.5" PICO-ITX |
| Dimensions (L)x(W)mm | 100mm x 72mm (3.94" x 2.84") |
| Processor |
Intel® 7th Gen Core™ i7/i5/i3/Celeron® processors Core™ i7-7600U 2.8GHz DC (15W) Core™ i5-7300U 2.6GHz DC (15W) Core™ i3-7100U 2.4GHz DC (15W) Celeron® 3965U 2.2GHz DC (15W) |
| Chipset | Intel® Kaby Lake-U processor integrated |
| BIOS | AMI UEFI Flash ROM |
| LAN Controller | Intel® I219LM GbE PHY w/ AMT (only Core™ i7/i5 prosessor support) |
| Audio Codec | Realtek ALC888S |
| Watchdog Timer | Yes |
| Memory | |
| Technology | DDR4 SDRAM up to 2133 MHz |
| Max. Capacity | Up to 16GB |
| Socket | 1 x 260-pin SO-DIMM |
| Display | |
| Graphic | Intel® HD Gen. 9-LP graphics |
| Display Interface | 1 x HDMI v1.4 (DP v1.2 co-layout optional), 1 x LVDS (Dual-channel 18/24-bit) 1 x AMIO (DP v1.2 optional) |
| I/O | |
| Expansion Slot |
1 x M.2 E-key 2230 (WiFi/BT) 1 x M.2 M-key 2242 (SSD) 1 x AMIO (optional) |
| LAN | 1 x 10/100/1000 Mbps |
| Serial ATA | 1 x SATAIII |
| Audio | Line-in, Line-out, Mic-in |
| USB | 2 x USB 3.0, 3 x USB 2.0 |
| COM | 1 x RS-232/422/485, 1 x RS-232 (either for DIO) |
| Display | 1 x HDMI (co-layout DP optional), 1 x AMIO (DP interface option), 1 x LVDS |
| Digital I/O | 1 x 8-bit (either for COM) |
| SMB | 1 x SMBus |
| PS/2 | N/A |
| Power Requirement | |
| Power connector | 1 x DC-Jack screw type or WF 1x2pin(optional) |
| Power Type | DC-IN 12V |
| Power Mode | AT/ATX (by jumper selection) |
| Environment | |
| Storage Temperature | -40°C ~ 80°C (-40°F ~ 176°F) |
| Relative Humidity | 0% ~ 95% (non-condensing) |
| Operating Temperature |
0°C ~ 60°C (32°F ~ 140°F) standard -20°C ~ 70°C ( -4°F ~ 158°F) optional -40°C ~ 70°C (-40°F ~ 158°F) optional |
