Heim / Produkte / Industrial Display / Durapixel™ - im Sonnenlicht ablesbare LCDs / 4301-B

im Sonnenlicht ablesbare LCDs

4301-B

43” TFT LCD, 3500nits LED Backlight, 1920x1080
  • High Brightness 3500 nits
  • Sunlight Readable
  • LED Backlight
  • Low Power Consumption
  • LCD Blacking Defect Free(Hi-Tni 110 ˚C)
  • BL MTBF: 100,000 hours
Drucken
Anfrage Vergleich
Spezifikationen DOWNLOAD
Model Name DLF4301-B DLH4301-B DLD4301-B
Description 43” TFT LCD, 3500nits LED Backlight, 1920x1080
size 43"
Display area (mm) 940.896(H) x 529.254(V)
Brightness 3500 cd/m²
Resolution 1920x1080
Aspect ratio 16:9
Contrast ratio 1600:1
Pixel pitch (mm) 0.49005(H) x 0.49005(V)
Pixel per inch (PPI) 51
Viewing angle 178° (H), 178° (V)
Color saturation (NTSC) 82%
Display colors 16.7M
Response time (Typical) 8ms
Video interface LVDS DVI-I, HDMI, DP
Input power   AC 100~240V
Power consumption 157W 163W
Dimensions (mm) 968.2(H)x 556.4(V)x 44.8(T)  971.60(H) x 559.79(V) x 88.0(T)
Bezel size (U/B/L/R) 13.572/13.572/13.652/13.652 15.27/15.27/15.35/15.35
Weight (Net) 11.6 kg 20.0 kg
Mounting   VESA 400x100
OSD key   4 keys (Power switch, menu, +, -)
OSD control   Brightness, Color, Contrast, Auto Turing, H/V Position…etc
Operating temperature -20 ˚C ~ 60 ˚C
Storage temperature -20 ˚C ~ 70 ˚C
