Stretch Digital Display

2445-MNW

24.4” Resizing LCD, 800 nits LED backlight, MaxRGB , 1920 x 540
  • 24.4” Resizing LCD
  • Ultra-Wide Screen (16 : 4.5)
  • High Brightness 800 nits
  • LED Backlight
  • High Color Saturation
  • Wide viewing angle 178°(H)~ 178°(V)
  • Low Power Consumption
  • BL MTBF: 100,000 hours

Main Features

  • Transportation

  • Sunlight Readable

  • MaxRGB

  • Low Power Consumption

Model Name

SSD2445-MNW

Description

24.4” Resizing LCD, 800 nits LED backlight, MaxRGB, 1920x540

Screen Size

24.4”

Display Area (mm)

597.6(H) x 168.07(V)

Brightness

800 cd/m2

Resolution

1920x540

Aspect Ratio

16 : 4.5

Contrast Ratio

4000 : 1

Pixel Pitch (mm)

0.31125(H) x 0.31125(V)

Pixel Per Inch (PPI)

81

Viewing Angle

178°(H),178°(V)

Color Saturation (NTSC)

90%

Display Colors

16.7M

Response Time (Typical)

20ms

Panel Interface

LVDS

Video Interface

HDMI, DP

Input Power

DC12V

Power Consumption

31.7W

OSD Key

4 Keys (Power Switch, Menu, +, -)

OSD Control

Brightness, Color, Contrast, Auto Turing, H/V Position…etc

Dimensions (mm)

626 x 201.5 x 44

Bezel Size(U/B/L/R)

16.7/16.7/14.2/14.2

Mounting (mm)

75x75, 250x75

Weight (Net)

3.5 kg

Operating Temperature

0 ˚C ~ 50 ˚C

Storage Temperature

-20 ˚C ~ 60 ˚C
