Stretch Digital Display

IPPS-0683

6.8” LCD, 700 nits LED backlight, 480 x 1280 ultra-wide aspect ratio 6:16
  • Ultra-Wide Screen (6 : 16)
  • Power input by Type-C or POE
  • Rockchip RK3566 2GB/16GB
  • High Resolution 480x1280
  • Brightness 700 nits
  • PCT(Multi-Touch)
  • Low Power Consumption
Drucken
Anfrage Vergleich

Main Features

  • Transportation

  • Sunlight Readable

  • Stretch Display

  • Low Power Consumption

  • Gaming

Spezifikationen DOWNLOAD
Model Name IPPC-0683-RKC4-NP00-1001
Description 6.8” LCD, 700 nits LED backlight, 480 x 1280
size 6.8”
Display area (mm) 60.19(H) x 160.51(V)
Brightness 700 cd/m2
Resolution 480x1280
Aspect ratio 6 : 16
Contrast ratio 900 : 1
Pixel pitch (mm) 0.1255(H) x 0.1255(V)
Pixel Per Inch (PPI) 199
Viewing angle 160°(H),160°(V)
Color Saturation (NTSC) 84%
Display Colors 16.7M
Panel Interface MIPI
Touch Interface USB
Input Power Type-C (DC 5V) or POE
CPU ROCKCHIP Quad-Core Cortex-A55
RAM、Storage LPDDR4 4GB/32GB eMMC
RAM 2GB LPDDR4
Storage 16GB eMMC
I/O Interface 1LAN/2USB(USB2.0+USB3.0)/1HDMI/1Type-C
Dimensions(mm) 70.70 x 207.30
Operating Temperature -5℃~60℃
